FibeAir IP features a powerful, integrated Ethernet switch for advanced networking solutions and an optional TDM cross-connect for nodal site applications. Tx Range (Manual/ATPC). 20dB dynamic range. System Specifications. FibeAir® IP Technical. Introducing FibeAir IP FibeAir IP is Ceragon’s next. March Reuven Ginat Describes the FibeAir IPE CLH Compact This manual is intended for use by Ceragon customers, potential customers.

EVOLUTION Firmware Update Installation Guide (373-0854) Smart Connect™ Firmware Update Installation Guide (373-0912). Wireless transport for ISPs – easier with Multicore technology. As a Wireless ISP, you need your wireless transport to be as agile as your business.High-capacity and fast time-to-market are the name of the game and are exactly what you can achieve with Ceragon’s IP-20 Platform. Innovative, flexible and cost-effective wireless backhaul and fronthaul solutions that enable mobile operators to deliver broadband services to their subscribers.

Lutilisation de commandes ou de rglages ou l’excution de procdures autres que celles spcifies dans les prsentes peut engendrer une exposition dangereuse aux rayonnements.! FibeAir provides a ground for each IDU, via a one-hole mounted lug onto a single-point stud.

Use of controls, adjustments, or performing procedures other than those specified herein, may result in hazardous radiation exposure. Labeling is specific to each customer.

Ceragon IP Manuals CLI Management Installation Licensing Troubleshooting

Software Downloader Free Download

Do not attempt to adjust the laser drive current. The Users window will be displayed. Verify SW files stored at C: Extract the file and run the installation setup. The following basic commands are available when you first log in, if you belong to the Operator user. Verify no Ethernet traffic cables or fibers connected. Open the IDU and go to: For access to the site, contact support ceragon. Mahual pole is secure and perpendicular.

Spread grease on the O-ring supplied with the flexible waveguide. Pass Pass Pass Pass 7. For a list of accessories, see Appendix D – Accessories.

Ceragon ip10 user manual. No part of this publication may be reproduced, modified, or distributed without prior written authorization of Ceragon Networks Ltd.

Ceragon FibeAir-IP10 Manual

Ceeagon example, the prompt for a unit located in slot. Machine noise information order – 3. It is the owners responsibility to obtain any and all permits. Configuring the IDUAfter the system is installed and tested, and antenna alignment is performed, the next step is IDU setup and configuration.

All fiber optic patch leads should be routed carefully and efficiently, using conduits to prevent damage to the cables.

arvid :: Ceragon ip 10 manual

Other names mentioned in this publication are owned by their respective holders. For connectors or signals labeled RX, the signals are sent to FibeAir. Insert the new fan tray entirely in its place and tighten the deragon screw. Mounting pole is grounded as per site specifications. Der Laserstrahl ist unsichtbar!! Make sure that the inner pin of the connector does not exceed the edge of the connector.

Ceragon IP-10 IDU CLI Commands List

OAM tools, this first-of-its-kind solution simplifies network design, reduces Ceragon ip10 user manual. Unpack the contents and check for damaged or missing parts.

As shown in the illustration above, the protection panel in the middle provides the ports used to link the two IP units for protection switching when a system fault occurs. Please contact your Ceragon representative for details. To prevent damage, before touching components inside the device, all electrostatic must be discharged from both personnel and tools. The FileZilla Server window will be displayed.

Upon completing the Commissioning Log, send the log to Ceragon support center at support ceragon. See the third point in the Antenna Mounting section above. Power supply grounding should be in accordance with the following illustration: Verify that the application reports the correct parameters when performing the above. Verify connectivity to IDU ping Unpack the contents and check for damaged or missing parts.

This sway brace should not be mounted to the same pole as the antenna, but should be installed directly back to the tower or an alternative point. Some antennas cerragon moisture drain plugs installed at various points around the antenna. Ceragon ip 10 manual.

FibeAir IP features a powerful, integrated Ethernet switch for advanced networking solutions and an optional TDM cross-connect for nodal site applications. Tx Range (Manual/ATPC). 20dB dynamic range. System Specifications. FibeAir® IP Technical. Introducing FibeAir IP FibeAir IP is Ceragon’s next. March Reuven Ginat Describes the FibeAir IPE CLH Compact This manual is intended for use by Ceragon customers, potential customers.

Post on Apr views. No part of this publication may be reproduced, modified, or distributed without prior written authorization of Ceragon Networks Ltd. This document is provided as is, without warranty of any kind. Other names mentioned in this publication are owned by their respective holders. Statement of ConditionsThe information contained in this document is subject to change without notice.

Manuql to UserAny changes or modifications of equipment not expressly approved by the manufacturer could void the users authority to operate the equipment and the warranty for such equipment. Copyright by Ceragon Networks Ltd. Tel AvivIsrael Tel: Ceragon Networks UK Ltd. A-1 GHz 1 Channels Before turning on the equipment, make sure that the fiber optic cable is intact and is connected to the transmitter.

Do not attempt to adjust the laser drive current. The laser beam is invisible! The use of optical devices with the ceragpn will increase eye hazard.

Use of controls, adjustments, or performing procedures other than those specified herein, may result in hazardous radiation exposure. Diconnecting one power supply disconnects only one power supply module. To isolate the unit completely, disconnect all mahual supplies. Machine noise information order – 3.

To prevent damage, before touching components inside the device, all electrostatic must be discharged from both personnel and tools. Avant de mettre l’quipement en marche, s’assurer que le cble fibre optique manuak intact et branch l’metteur.

Ceragon IP-10 IDU CLI Commands List

Ne pas essayer de rgler le courant de commande du laser. Lutilisation de dispositifs optiques avec l’quipement augmente le danger pour les yeux. Lutilisation de commandes ou de rglages ou l’excution de procdures autres que celles spcifies dans les prsentes peut engendrer une exposition dangereuse aux rayonnements.!

Pour isoler compltement l’unit, il faut dbrancher toutes les alimentations lectriques.! Bruit de machine dordre – 3. SicherheitsmanahmenVorsichtsmanahmen bei faseroptischen Leitungen! Vergewissern Sie sich vor dem Einschalten der Anlage, dass das faseroptische Kabel unbeschdigt und mit dem Sender verbunden ist.

Versuchen Sie nicht, den Laser-Antriebsstrom zu regulieren.

CONOCIENDO RADIO CERAGON IP10 by Reynaldo Gutierrez Delgado on Prezi

Der Laserstrahl ist unsichtbar!! Durch den Einsatz optischer Gerte zusammen mit der Anlage erhht sich das Gesundheitsrisiko fr die Augen. Wenn andere Steuerelemente verwendet, Einstellungen vorgenommen oder Verfahren durchgefhrt werden als die hier angegebenen, kann dies gefhrliche Strahlung verursachen.! Durch Abtrennen einer Stromquelle wird nur ein Stromversorgungsmodul abgetrennt. Um die Einheit vollstndig zu isolieren, trennen Sie alle Stromversorgungen ab.!

This innovative platform uses an on-the-fly upgrade method, whereby network operators only buy capacity as needed, benefiting from savings on initial investments and OPEX. Traffic capacity throughput and spectral efficiency are optimized with the desired channel bandwidth. High spectral efficiency is ensured using the same bandwidth for double the capacity, via two carriers, with vertical and horizontal polarizations.

This feature is implemented by a built-in XPIC mechanism. RFU-C works together with two types of indoor units. This enables double capacity in the same spectrum bandwidth.

If needed, change the antenna polarization by rotating the RFU-C in accordance with the relevant antenna installation guide.

Ceragon FibeAir-IP10 Manual

Vertical Pole Horizontal Pole2. Spread grease on the O-ring supplied with the antenna. Place the O-ring in its location on the antenna transition.

Remove the sticker from the RFU-C antenna interface.

Mount the RFU-C on the antenna according to the system configuration, and make sure that the twist is set for mabual desired polarization horizontal or vertical. Insert four screws and washers provided with the kit, and tighten them.

If needed, change the antenna polarization according to the cerayon antenna installation guide. Spread grease on the two O-rings supplied with the kit and place them in their locations. Mount the twist on the coupler according to the relevant antenna polarization as shown in the illustrations belowusing four screws and washers supplied with the kit.

Place the O-ring on the antenna transition. Mount the coupler holder on the antenna using the screws and cerwgon supplied with the kit. Spread grease on the Cerago supplied with the holder coupler kit. Place one O-ring on each side of the coupler.

Remove the sticker from both RFU-C antenna interfaces. Mount both RFU-Cs on the holder coupler. For each RFU-C, insert four screws and washers, and tighten them, as shown in the following illustration. Mount the Ceragon remote mount device on the pole, as shown in the following illustration.

Insert four screws and washers, and tighten them. Spread grease on the O-ring supplied with the flexible waveguide. Place the O-ring in the flexible waveguide flange groove. Place majual O-ring in the other end of the flexible waveguide flange groove. Mount the flexible waveguide on the antenna, and tighten the screws and washers. Mount the Ceragon remote mount device on the pole.

Mount the coupler holder on the Xeragon remote mount device using the screws and washers supplied with the kit. Spread grease on the O-rings supplied with the coupler holder kit. Mount both RFU-Cs on the coupler holder. For each RFU-C, insert four screws and washers, and tighten them. Mount the flexible waveguide on the Mwnual coupler, and tighten the screws and washers. The antenna interface is always the RFU-C interface. If other antennas are to be used, an adaptor with a 0.

The numbers above are typical losses per component.

Ceragon Software Download For Pc

IPG-Install-Guide-Filezilla | David José Barrios Itriago –

An adapter is used for the direct mount, as shown in the following illustration. WTG seriesFor remote mount installations, the following flexible waveguide flanges should be used millimetric. The same antenna type mznual as indicated above can be used recommended. Other antenna types using the flanges listed in the table below may be used.

Please contact your Ceragon representative for details. TransportationThe equipment should be prepared for public transportation.

Software Download Windows 7

The cargo must be kept dry during transportation, in accordance with ETSClass 2. It is recommended that the equipment be transported to the installation site in its original packing case. If intermediate storing is required, the packed equipment must be stored in a dry and cool environment, and out of direct sunlight, in accordance with ETSClass 1.

InspectionCheck the packing lists and verify that the correct equipment part numbers and quantities are found in the packages that arrived. Acceptance and commissioning should be performed after initial setup is complete. The purpose of this procedure is to verify correct installation and operation of the installed link and the interoperability with customer end equipment.

Ceragon’s Acceptance and Commissioning procedure includes the following stages: Following this procedure will ensure proper, long-lasting, and safe operation of the product. The checklist below summarizes the installation requirements of the site. Mount is of sufficient height to clear local obstructions Mount is safely positioned to not cause a safety hazard Mount is secure and perpendicular Mount is grounded as per site specifications All steelwork is Galvanized or Stainless Steel as appropriate 3.

Remote mount kit is securely mounted to the pole Waveguide has no physical damage and connectors are sealed All waveguide bolts are secured using washers and lockwashers, as appropriate Flexible waveguide is secured to the pole 6. All bends are per manufacturer specifications WG ends are properly labeled 8.

Power-Supply is properly grounded DC power backup type: Antenna Mounting Mounting pole is of sufficient height to clear local obstructions, such as parapets, window cleaning gantries, and lift housings. Mounting Pole is of sufficient height, and is safely positioned, so as not to cause a safety hazard. No person should be able to walk in front of, or look directly into the path of the microwave radio beam. Where possible, the pole should be away from the edge of the building.

Mounting pole is secure and perpendicular. A pole that is not perpendicular may cause problems during antenna alignment. Mounting pole is grounded as per site specifications.

All operators and site owners have specific requirements regarding the grounding of installations. As a minimum, typical requirements are such that any metal structure must be connected to the existing lightning protection ground of the building.
